SKU: 56-QM.

DRUM MOWERS

1488 kg | 3875 lbs

Weight (Excluding Boom Adapter & Pins)

260 bar | 3771 psi

Rotator Pressure

1422 mm | 56"

Cutting Swath

2000 rpm

Speed

Drum Mower Attachment Heads are extremely heavy-duty drum mowers. When paired with Quadco Mower Teeth, they provide a complete mulching system. They are capable of mulching vegetation into fine material and they have an optional boom adapter with matching pins or quick attach available for most carriers.

56QDM

Standard Configuration
Metric
Imperial

Weight (Excluding Boom Adapter & Pins) 1,488 kg 3,875 lbs
Height 1,245 mm 49″
Width 813 mm 32″
Length 1,803 mm 71″

Cutting Swath 1,422 mm 56″
Number of Teeth 26
Speed 2,200 rpm

Motor Rexroth
Motor Size 170 cc
Minimum Flow 170 lpm 45 gpm
Pressure 260 bar 3,771 psi
Weight 3300 kg
Dimensions 30 × 30 × 40 cm

Reviews

There are no reviews yet.

Add a review

it’s all in the details

As a true visionary and pioneer in the forestry industry, we embrace quality craftsmanship.

DRUM MOWERS

The low-maintenance and easy-to-operate Quadco Mower Mulchers grind vegetation into a fine material.

Capable of performing extensive operations–from light brushing and clearing to full tree mulching–they’re ideal for keeping operating costs down while achieving maximum efficiency in land clearing.

DRUM MOWER 45-QDM 56-QDM
Cutting Capacity 45″ 56″
