Intermittent models are capable of shoveling wood, cutting individual large limbs, and topping large trees. They have an optional locking arms safety feature available for projects involving electrical wires. These heads are ideal for blow-down and right-of-way clearing due to their hold and cut tree control.
|
|
|
|
| STANDARD CONFIGURATION | METRIC | IMPERIAL |
|---|---|---|
WEIGHTS & DIMENSIONS | ||
Rotation 40° (High Torque) | 2,812 kg | 6,200 Ibs |
Rotation 360° (High Torque) | 2,994 kg | 6,600 Ibs |
Height | 2,997 mm | 118"" |
Width | 1,346 mm | 53"" |
Depth | 1,524 mm | 60"" |
DISC | ||
Cutting Capacity | 610 mm | 24"" |
Rated Saw Speed | 760 rpm | |
Number of Teeth | 12 | |
Saw Kerf | 41 mm | 1 5/8"" |
SAW DRIVE | ||
Motors | Two F12-30 | |
Pinion | 1 Cylinder | |
Rated Saw Speed | 117 fps | |
CARRIER REQUIREMENTS | ||
Carrier Size | 22 ton & plus | |
PSI Working Pressure | 248 – 276 bars | 3,600 – 4,000 psi |
Valve Section Saw Circuit | 284 lpm | 75 gpm |
Low Flow Valves for Arms & Rotator | Yes |
