C Models enable better leverage when handling tall timber with extended tower and faster accumulation. They feature stronger, more durable cast arms contoured for maximum support when accumulating as well as an ultra-reliable disc drive with easily adjustable bearings.
|
|
|
|
| STANDARD CONFIGURATION | METRIC | IMPERIAL |
|---|---|---|
WEIGHTS & DIMENSIONS | ||
Rotation 40° (Medium Torque) | 2,141 kg | 4,720 lbs |
Rotation 360° (Medium Torque) | 2,263 kg | 5,175 lbs |
Height | 2,642 mm | 104"" |
Width | 1,499 mm | 59"" |
Depth | 1,295 mm | 51"" |
Maximum Throat Opening | 762 mm | 30"" |
Maximum Throat Opening @ Teeth | 737 mm | 29"" |
Accumulation Area | 0.28 m² | 3.0 ft² |
DISC | ||
Cutting Capacity | 457 mm | 18"" |
Tip-to-Tip Diameter | 1,219 mm | 48"" |
Rated Saw Speed | 1,350 rpm | |
Number of Teeth | 18 | |
Saw Kerf | 51 mm | 2"" |
Weight (Holders & Teeth | Varies Depending on Disc) | 227 – 240 kg | 500 – 530 lbs |
Style (One Piece or Segmented) | Both | |
HYDRAULICS | ||
Grab Arms | 1 Cylinder | |
Accumulating Arms | 1 Cylinder |
