Dangle

412 kg | 908 lbs

Weight (without rotator, link, or multi-tree handling)

210 bar | 3,046 psi

Rotator Pressure

330 mm | 13 in

Cutting Capacity

470 mm | 18.5 in

Maximum Opening Diameter
Download Product Sheet

The Log Max 928A features a hydraulically driven saw with pressure controlled sawing force and flow controlled chain speed. The high performance saw hydraulics provide full flow to the bottom saw resulting in fast cutting. This saw unit is able to fell trees up to 420 mm.

928

Standard Configuration
Metric
Imperial
Weight 412 kg 908 lbs
Height 1,031 mm 40.6″
Maximum Width (With Head Open) 1,005 mm 39.6″
Maximum Width (With Head Closed) 818 mm 32.2″
Degree of Rotation N/A
Number of Drive Rollers 2
Motor Size (Drive Arm) 365 cc 22.3 in3
Motor Size (Variable Displacement) N/A N/A
Motor Size (Fixed Center Drive) N/A N/A
Maximum Drive Roller Opening (Diameter) 330 mm 13.0″
Maximum Drive Roller Closing (Diameter) 12 mm 0.5″
Feed Speed 3.1 mps 10.2 fps
Number of Delimb Arms N/A
Maximum Delimb Opening 470 mm 18.5″
Maximum Delimb Full Coverage 245 mm 9.7″
Minimum Delimb Closing (Diameter) 20 mm 0.8″
Saw Type Saw 928A
Maximum Cut (Diameter) 42 cm 16.5″
Bar Size 48 cm | 42 cm 18.9 “| 16.5”
Chain Pitch 0.404 mm
Motor Size 10 cc 2.64 in3
Chain Auto Tension No
Oil Tank Capacity 4.5 L 1.19 gal
Carrier Size (Tracked) 7 – 15 ton
Carrier Size (Wheeled) 6.5 – 13 ton
Maximum Pressure 210 bar 3,046 psi
Model Log Mate 510
Optional Additions Yes
Full Optimization Optional
Electronic Calipers (For Electronic Calibrations) Optional
Degree of Rotation N/A

Description

The Log Max 928A features a hydraulically driven saw with pressure controlled sawing force and flow controlled chain speed. The high performance saw hydraulics provide full flow to the bottom saw resulting in fast cutting. This saw unit is able to fell trees up to 420 mm.

Reviews (0)

Reviews

There are no reviews yet.

Add a review

Next

it’s all in the details

As a true visionary and pioneer in the forestry industry, we embrace quality craftsmanship.

download product sheet

bar saw models

download product sheet

With the ability to handle up to 32” in a single cut, Quadco Bar Saws are ready to tackle your large timber with finesse.

“Stop and go” versatility means the bar saw is retracted after the cut, safely readying the head for your delimbing, topping, and trimming needs.

Our Bar Saw’s arms are extremely durable, feature one cylinder per arm, and are made of cast-iron steel for easy grabbing and accumulating.

bar saw models qb2500 qb3200 qb3500 qb4400
Cutting Capacity 25″ 32″ 34″ 39″
